RO Membrane 4040,Brackish Water RO membrane BW-8040, Reverse Osmosis Membrane

FOB Reference Price:Get Latest Price
$55.00 - $275.00 / Piece | 5 Piece/Pieces (Min. Order)
Model Number:
ro membrane
Report Suspicious Activity
Overview
Quick Details
Warranty:
5 years
After-sales Service Provided:
Online support
Place of Origin:
Anhui, China
Brand Name:
Huamo
Standard desalting rate:
99.4%-99.75%
Opearting pressure psi(mpa):
100-800
brand:
Runmo/OEM
Function:
Key parts of Water Treatment system
Membrane Film:
Dry or Wet as your request
Size:
4021,4040,8040
Material:
Composite Polyamide
OEM/ODM:
Available
Supply Ability
Supply Ability:
100000 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
carton or as customer require,Pallets packing
Port
Shanghai/Shenzhen/Guangdong

Runmo RO Membrane ULP-4040,Brackish Water RO membrane BW-8040,  Reverse Osmosis Membrane



 Ultra Low Pressure ULP Series,Brackish Water BW Series,Fouling Resistant Reverse Osmosis Membrane ,Industrial nanofiltration ro membrane and Residential Ro membranes.Price is  competitive.

desalinization rate,salt  rejection :99.5%-99.7%, : whatsapp: +8613856082854

 Brief Introduction:




1.Ultra Low Pressure ULP Series RM-ULP-8040/4040/4021



Test conditions:
Test pressure:..........225 psi(1.55Mpa)
Temperature of Testing solution: ........25℃
Concentration of Solution (Nacl) ........2000PPM
PH Value of Solution ..........7.5
Single Elment Recovery.........15%

Operation Conditions:

Max working Pressure: 600 psi (4.14Mpa)
Max Feedwater flow rate: 75gpm(17M3/H) (8040)
16gpm(3.6M3/H)(4040)
Max feedwater Temperature: 45 ℃
Max Feedwater SDI: 5
Free chlorine Concentration of Feedwater: < 0.1PPM
PH Range of Feedwater During continuous Operation: 3-10
PH Range of Feedwater During Chemical Cleaning: 2-12
Max pressure Drop of single Membrane Element: 15 psi(0.1Mpa)



    1) Data sheet

Style No



Membrane

Area

ft2(m2)

Testing

Pressure

psi(MPa)

Pernate

Flow

GPDG(T)

Destlinization(%)

Recovery(%)

RM-ULP-4021

36 (3.3 )

150 ( 1.05 )

1000 (3.8 )

99.0

8

RM-ULP-4040

78 (7.2)

150 ( 1.05 )

2500 ( 9.5 )

99.5

15

RM-ULP-8040

400 (37)

150 ( 1.05 )

10500( 39.5)

99.5

15



2.Brackish Water BW Series  RM-BW-8040/8365/4040/4021



Test conditions:
Test pressure:..........70 psi
Temperature of Testing solution: ........25℃
Concentration of Solution (Nacl) ........2000PPM
PH Value of Solution ..........7.5-8
Single Elment Recovery.........15%

Operation Conditions:

Max working Pressure: 600 psi (4.14Mpa)
Max feedwater Temperature: 45 ℃
Max Feedwater SDI: 5
Free chlorine Concentration of Feedwater: < 0.1PPM
PH Range of Feedwater During continuous Operation: 3-10
PH Range of Feedwater During Chemical Cleaning: 2-12
Max pressure Drop of single Membrane Element: 15 psi(0.1Mpa)



Style No



Membrane

Area

ft2(m2)

Testing

Pressure

psi(MPa)

Pernate

Flow

GPDG(T)

Destlinization(%)

Recovery(%)

RM-BW-4021

36 (3.3 )

225( 1.55 )

900 (3.4 )

99.3

8

RM-BW-4040

78 (7.2)

225 ( 1.55 )

2500 (9.5 )

 99.5

15

RM-BW-8365

365 (34)

225 ( 1.55 )

9500(35.9)

99.5

15

RM-BW-8040

400 (37)

225 ( 1.55 )

10500 (39.7 )

99.5

15



 3.Fouling Resistant BW Series  RM-BW-8400FR/8356FR/4040FR



Test conditions:
Test pressure:..........225 psi(1.55Mpa)
Temperature of Testing solution: ........25℃
Concentration of Solution (Nacl) ........2000PPM
Concentration of Solution (MgSO4)........2000PPM
PH Value of Solution ..........7.5
Single Elment Recovery.........15%

Operation Conditions:

Max working Pressure: 600 psi (4.14Mpa)
Max Feedwater flow rate: 75gpm(17M3/H) (8040)
16gpm(3.6M3/H)(4040)
Max feedwater Temperature: 45 ℃
Max Feedwater SDI: 5
Free chlorine Concentration of Feedwater: < 0.1PPM
PH Range of Feedwater During continuous Operation: 3-10
PH Range of Feedwater During Chemical Cleaning: 2-12
Max pressure Drop of single Membrane Element: 15 psi(0.1Mpa)



   1)date sheet

Style No



Membrane

Area

ft2(m2)

Testing

Pressure

psi(MPa)

Pernate

Flow

GPDG(T)

Destlinization(%)

Recovery(%)

RM-BW-4040FR

78 (7.2)

225( 1.55 )

2200 (8.3 )

99.5

15

RM-BW-8365FR

365 (34)

225 ( 1.55 )

9500(35.9)

 99.5

15

RM-BW-8400FR

400 (37)

225 ( 1.55 )

10500 (39.7 )

99.5

15



 4.Nanofiltration Membrane NF Series  RM-NF-8040/4040



Test conditions:
Test pressure:..........70 psi
Temperature of Testing solution: ........25℃
Concentration of Solution (Nacl) ........2000PPM
Concentration of Solution (MgSO4)........2000PPM
PH Value of Solution ..........7.5
Single Elment Recovery.........15%

Operation Conditions:

Max working Pressure: 600 psi (4.14Mpa)
Max feedwater Temperature: 45 ℃
Max Feedwater SDI: 5
Free chlorine Concentration of Feedwater: < 0.1PPM
PH Range of Feedwater During continuous Operation: 3-10
PH Range of Feedwater During Chemical Cleaning: 2-12
Max pressure Drop of single Membrane Element: 15 psi(0.1Mpa)



Style No



Membrane

Area

ft2(m2)

Testing

Pressure

psi(MPa)

Pernate

Flow

GPDG(T)

Destlinization(%)

Recovery(%)

RM-NF-4040

78 (7.2)

70 (0.48 )

2200 (8.3 )

80-90

15

RM-NF-8040

400 (37)

70 ( 0.48 )

10500 (39.7 )

80-90

15


 FAQ

Q1. Can I have a sample order for RO Membrane?

A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.

Q2. What about the lead time?

A:Sample needs 7 days, mass production needs 7-15 days after the payment.

Q3. Do you have any MOQ limit for RO Membrane?

A: Low MOQ, 1pc for sample checking is available

Q4. Is it OK to print my logo on RO Membrane?

A: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.
